Smoke Generator For Cars Leak Tester Fuel Leakage Detector Automotive Smoke Machine
USE A SMOKE MACHINE TO FIND ENGINE VACUUM AND OTHER LEAKS
When it comes to larger diesel engines, a loss of integrity through the induction system is often more elusive. By smoke testing the induction pathway, you can quickly locate leaks in connections and hoses, the turbocharger, and intercooler, along with engine gaskets such as at the intake manifold. Often a series of small leaks in the turbocharger system present as something much more serious and expensive than porous tube connections.
Other aspects of machinery can be smoke tested such as fuel and hydraulic lines, coolant systems, or storage tanks.
There are myriad smoke test machines on the market. They all use a safe chemical to make smoke and may include the ability to introduce a dye to make detection easier. Automotive-style smoke testers usually put very low pressure into the system being tested and rely on the smoke finding its way out. Larger and more complex and costly units will have the ability to pressurize the system to normal operating conditions.
Products Description
CL663 Smoke Automotive Leak Locator is an innovative product that provide safe and convenient method to check leaks in automotive systems. Its so far the fastest way of detecting & locating the leak position of all pipe system in an vehicle at an affordable price, every garage and workshop will need one.
Professional, Flexible, Affordable
Easy to Operate
Fast in helping locate the leak
Multi-functional
Adjustable LED function time control
Adjustable flow control
Inbuild air compressor
Stable output pressure
Best mate for automotive scanner
Product parameter:
Output pressure:35~42Psi
Output flow:4L/Min
Power supply: 12V
Air source: built-in
Test oil capacity:10ML
Dimensions of the Main Unit 198 x 320 x 246mm
Package weight:3.8KG
Feature
Simple To Operate
The Smoke Automotive Leak Locator is easily controlled with a timer
setting and flow control. Set the timer then the machine will
generate smoke, and control the flow with the flow controller.
The output is regulated to 12~14 Inches of Water Column, this
pressure is perfect to perform leak test of EVAP system and other
automotive systems with no damage to the vehicle sealing.
Save time and fast leak detect
In most cases, a scan tool may find out pressure sensors abnormal etc., while actully the 'pressure low' problem is caused by leak somewhere.
Multi-function
The Smoke Automotive Leak Locator is a multi purpose tool essential
for EVAP system, but also applicable for: EGR valves, Gaskets &
Fittings, Hoses, Worn Throttle shafts, Break Boosters, Catalytic
Converters, Oil Leaks, Lamp Housings, manifolds and more....
LED time indicator, Adjustable air flow and 1 ~ 20 minutes
adjustable operating time
Adjustable timer and air flow to perform leak test on different
system that requires different flow amount.
Notes:
* Please do leak detection away from smoke-sensitive parts.
* Do not run the detector over 8 minutes. It needs interval rest.
* The detector has protector. If it exceeds working limit, it will
power off automatically. In this condition, please operate it
later.
* The round parts of this detector is with temperature, be careful
to avoid scalding injury.
The following figure is suggested to be checked on the computer
